LINY STALOWE
Standardowe (ocynkowane)
   |
||||
|
Ø liny [mm] 6x7 |
Minimalna siła niszcząca (MBF) [kN] | |||
|---|---|---|---|---|
| 1770MPa | 1960MPa | |||
| FC | IWRC | FC | IWRC | |
| 1,8 | 1,90 | 2,06* | 2,11 | 2,28* |
| 2,0 | 2,35 | 2,54* | 2,60 | 2,81* |
| 2,5 | 3,67 | 3,97* | 4,07 | 4,40* |
| 3,0 | 5,29 | 5,72* | 5,86 | 6,33* |
| 3,5 | 7,20 | 7,78* | 7,97 | 8,62* |
| 4,0 | 9,40 | 10,20 | 10,40 | 11,30 |
| 5,0 | 14,70 | 15,90 | 16,30 | 17,60 |
| 6,0 | 21,20 | 22,90 | 23,40 | 25,30 |
| 7,0 | 28,80 | 31,10 | 31,90 | 34,50 |
| 8,0 | 37,60 | 40,70 | 41,60 | 45,00 |
| 9,0 | 47,60 | 51,50 | 52,70 | 57,00 |
| 10,0 | 58,80 | 63,50 | 65,10 | 70,40 |
| 11,0 | 71,10 | 76,90 | 78,70 | 85,10 |
| 13,0 | 99,30 | 107,00 | 110,00 | 119,00 |
| 14,0 | 115,00 | 125,00 | 128,00 | 138,00 |
| 16,0 | 150,00 | 163,00 | 167,00 | 180,00 |
| 18,0 | 190,00 | 206,00 | 211,00 | 228,00 |
   |
||||
|---|---|---|---|---|
|
Ø liny [mm] 6x19 |
Minimalna siła niszcząca (MBF) [kN] | |||
| 1770MPa | 1960MPa | |||
| FC | IWRC | FC | IWRC | |
| 3,0 | 4,89 | 5,29* | 5,42 | 5,86* |
| 3,5 | 6,66 | 7,20* | 7,37 | 7,97* |
| 4,0 | 8,69 | 9,40* | 9,63 | 10,40* |
| 5,0 | 13,60 | 14,70* | 15,00 | 16,30* |
| 6,0 | 19,60 | 21,20 | 21,70 | 23,40 |
| 7,0 | 26,60 | 28,80 | 29,50 | 31,90 |
| 8,0 | 34,80 | 37,60 | 38,50 | 41,60 |
| 9,0 | 44,00 | 47,60 | 48,70 | 52,70 |
| 10,0 | 54,30 | 58,80 | 60,20 | 65,10 |
| 11,0 | 65,80 | 71,10 | 72,80 | 78,70 |
| 12,0 | 78,20 | 84,60 | 86,60 | 93,70 |
| 13,0 | 91,80 | 99,30 | 102,00 | 110,00 |
| 14,0 | 107,00 | 115,00 | 118,00 | 128,00 |
| 16,0 | 139,00 | 150,00 | 154,00 | 167,00 |
| 17,0 | 157,00 | 170,00 | 174,00 | 188,00 |
| 18,0 | 176,00 | 190,00 | 195,00 | 211,00 |
| 19,0 | 196,00 | 212,00 | 217,00 | 235,00 |
| 20,0 | 217,00 | 235,00 | 241,00 | 260,00 |
| 21,0 | 240,00 | 259,00 | 265,00 | 287,00 |
| 22,0 | 263,00 | 284,00 | 291,00 | 315,00 |
| 23,0 | 287,00 | 311,00 | 318,00 | 344,00 |
| 24,0 | 313,00 | 338,00 | 347,00 | 375,00 |
   |
||||
|---|---|---|---|---|
|
Ø liny [mm] 6x37 |
Minimalna siła niszcząca (MBF) [kN] | |||
| 1770MPa | 1960MPa | |||
| FC | IWRC | FC | IWRC | |
| 5,0 | 13,10 | 14,10* | 14,50 | 15,60* |
| 6,0 | 18,80 | 20,30* | 20,80 | 22,50* |
| 7,0 | 25,60 | 27,70 | 28,30 | 30,60 |
| 8,0 | 33,40 | 36,10 | 37,00 | 40,00 |
| 9,0 | 42,30 | 45,70 | 46,80 | 50,60 |
| 10,0 | 52,20 | 56,50 | 57,80 | 62,50 |
| 11,0 | 63,20 | 68,30 | 70,00 | 75,70 |
| 12,0 | 75,20 | 81,30 | 83,30 | 90,00 |
| 13,0 | 88,20 | 95,40 | 97,70 | 106,00 |
| 14,0 | 102,00 | 111,00 | 113,00 | 123,00 |
| 15,0 | 117,00 | 127,00 | 130,00 | 141,00 |
| 16,0 | 134,00 | 145,00 | 148,00 | 160,00 |
| 18,0 | 169,00 | 183,00 | 187,00 | 203,00 |
| 19,0 | 188,00 | 204,00 | 209,00 | 226,00 |
| 20,0 | 209,00 | 226,00 | 231,00 | 250,00 |
| 21,0 | 230,00 | 249,00 | 255,00 | 276,00 |
| 22,0 | 253,00 | 273,00 | 280,00 | 303,00 |
| 23,0 | 276,00 | 299,00 | 306,00 | 331,00 |
| 24,0 | 301,00 | 325,00 | 333,00 | 360,00 |
| 25,0 | 326,00 | 353,00 | 361,00 | 391,00 |
| 26,0 | 353,00 | 382,00 | 391,00 | 423,00 |
| 27,0 | 381,00 | 412,00 | 422,00 | 456,00 |
| 28,0 | 409,00 | 443,00 | 453,00 | 490,00 |
| 29,0 | 439,00 | 475,00 | 486,00 | 526,00 |
| 30,0 | 470,00 | 508,00 | 520,00 | 563,00 |
| 31,0 | 502,00 | 543,00 | 556,00 | 601,00 |
| 32,0 | 535,00 | 578,00 | 592,00 | 640,00 |
| 34,0 | 604,00 | 653,00 | 668,00 | 723,00 |
| 36,0 | 677,00 | 732,00 | 749,00 | 810,00 |
  |
||||
|---|---|---|---|---|
|
Ø liny [mm] 6x36 |
Minimalna siła niszcząca (MBF) [kN] | |||
| 1770MPa | 1960MPa | |||
| FC | IWRC | FC | IWRC | |
| 8,0 | 37,40 | 40,30 | 41,40 | 44,70 |
| 9,0 | 47,30 | 51,00 | 52,40 | 56,50 |
| 10,0 | 58,40 | 63,00 | 64,70 | 69,80 |
| 11,0 | 70,70 | 76,20 | 78,30 | 84,40 |
| 12,0 | 84,10 | 90,70 | 93,10 | 100,00 |
| 13,0 | 98,70 | 106,00 | 109,00 | 118,00 |
| 14,0 | 114,00 | 124,00 | 127,00 | 137,00 |
| 15,0 | 131,00 | 142,00 | 146,00 | 157,00 |
| 16,0 | 150,00 | 161,00 | 166,00 | 179,00 |
| 17,0 | 169,00 | 182,00 | 187,00 | 202,00 |
| 18,0 | 189,00 | 204,00 | 210,00 | 226,00 |
| 19,0 | 211,00 | 227,00 | 233,00 | 252,00 |
| 20,0 | 234,00 | 252,00 | 259,00 | 279,00 |
| 22,0 | 283,00 | 305,00 | 313,00 | 338,00 |
| 23,0 | 309,00 | 333,00 | 342,00 | 369,00 |
| 24,0 | 336,00 | 363,00 | 373,00 | 402,00 |
| 25,0 | 365,00 | 394,00 | 404,00 | 436,00 |
| 26,0 | 395,00 | 426,00 | 437,00 | 472,00 |
| 27,0 | 426,00 | 459,00 | 472,00 | 509,00 |
| 28,0 | 458,00 | 494,00 | 507,00 | 547,00 |
| 30,0 | 526,00 | 567,00 | 582,00 | 628,00 |
| 32,0 | 598,00 | 645,00 | 662,00 | 715,00 |
| 34,0 | 675,00 | 728,00 | 748,00 | 807,00 |
| 36,0 | 757,00 | 817,00 | 838,00 | 904,00 |
| 38,0 | 843,00 | 910,00 | 934,00 | 1008,00 |
| 40,0 | 935,00 | 1008,00 | 1035,00 | 1116,00 |
| 42,0 | 1030,00 | 1112,00 | 1141,00 | 1231,00 |
| 44,0 | 1131,00 | 1220,00 | 1252,00 | 1351,00 |
| 46,0 | 1236,00 | 1333,00 | 1369,00 | 1476,00 |
| 48,0 | 1346,00 | 1452,00 | 1490,00 | 1608,00 |
| 50,0 | 1460,00 | 1575,00 | 1617,00 | 1744,00 |
| 52,0 | 1579,00 | 1704,00 | 1749,00 | 1887,00 |
| 54,0 | 1703,00 | 1837,00 | 1885,00 | 2036,00 |
| 56,0 | 1832,00 | 1976,00 | 2028,00 | 2190,00 |
| 58,0 | 1964,00 | 2121,00 | 2175,00 | 2349,00 |
| 60,0 | 2102,00 | 2270,00 | 2328,00 | 2514,00 |
| 62,0 | 2244,00 | 2424,00 | 2485,00 | 2684,00 |
| 64,0 | 2392,00 | 2583,00 | 2648,00 | 2860,00 |
| 66,0 | 2543,00 | 2747,00 | 2816,00 | 3042,00 |
| 68,0 | 2700,00 | 2916,00 | 2990,00 | 3229,00 |
| 70,0 | 2861,00 | 3090,00 | 3168,00 | 3422,00 |
| 72,0 | 3027,00 | 3269,00 | 3352,00 | 3620,00 |
 |
||||
